RS485 Long Distance Measuring Oem Laser Distance Sensor

Short Description:

RS485 long distance measuring sensor 100m Oem Laser Distance Sensor.RS485 is a communication standard commonly used in industrial applications for long-distance data transmission. It allows for multi-drop communication, meaning multiple devices can be connected to the same communication line.

An OEM laser distance sensor is a sensor that uses laser technology to accurately measure distances. It is typically used in industrial automation, robotics, and other applications where precise distance measurements are required.

When an OEM laser distance sensor is equipped with an RS485 interface, it means that it can be connected to a RS485 network for data transmission. This allows for long-distance communication between the sensor and other devices or systems.

The RS485 interface provides several benefits for long-distance measuring with an OEM laser distance sensor. It allows for communication over distances of up to 100m/150m, depending on the baud rate and cable quality. It also supports high-speed data transmission, making it suitable for applications that require real-time distance measurements.

Additionally, the RS485 interface allows for multi-drop communication, meaning multiple sensors can be connected to the same network. This simplifies the wiring and reduces the overall cost of the system.

In summary, an RS485 interface on an OEM laser distance sensor enables long-distance communication and multi-drop connectivity, making it ideal for applications that require accurate distance measurements over extended distances.. It is often used in applications such as construction, surveying, robotics, and automation.

Measuring range: 0.03~100m/150m

Accuracy: +/-3mm

Frequency: 3Hz

Interface: RS485

Voltage: DC5~32V

Laser: Class 2, 620~690nm, <1mW

More detailed product data sheet and quotation, please send email to us sales@seakeda.com !

Send email to us WhatsApp Email

Share this page:

Product Detail

Product Tags

Product Introduction

RS232 Long Range 150m Industrial Laser Rangefinder Module is designed for industrial applications requiring accurate distance measurement up to 150m. The rangefinder module utilizes laser technology to provide precise measurements in a variety of industrial environments.

The main functions of this module include:

Long-distance measurement: The industrial laser rangefinder has a measurement range of up to 150 meters and can accurately measure distances in a wide range.

Industrial-Grade Design: The IP54 protection rating ensures reliable performance in industrial environments.

RS232 interface: The laser rangefinder has an RS232 interface, which can be easily integrated with various industrial systems and equipment.

Laser Technology: This rangefinder module utilizes laser technology to provide highly accurate distance measurements.

Ease of Integration: The laser rangefinder module is designed for easy integration into industrial systems, featuring a simple communication protocol and a compact form factor.

Applications for this module include logistics and warehousing, construction, robotics, agriculture, and more. It can be used for distance measurement, object detection, liquid level monitoring, and other applications in industrial environments that require accurate distance measurement.

When considering this long distance laser rangefinder, it is important to ensure compatibility with your existing system and to evaluate whether the measurement range and performance specifications meet your specific requirements. Contact an expert to get more details!

Parameters of OEM Laser Rangefinder

Model	B93	Frequency	3Hz
Measuring Range	0.03~150m	Size	786728mm
Measuring Accuracy	±3mm	Weight	72g
Laser Grade	Class 2	Communication Mode	Serial Communication, UART
Laser Type	620~690nm,<1mW	Interface	RS232(TTL/USB/RS485/ Bluetooth can be selected)
Working Voltage	5~32V	Working Temperature	0~40℃(Wide temperature -10 ℃ ~ 50 ℃ can be customized)
Measuring Time	0.4~4s	Storage Temperature	-25℃-~60℃

Note:

1. Under bad measure condition, like environment with strong light or the diffuse reflectance of measuring point over-high or low, the accuracy would have bigger amount of error:±3 mm+40PPM.

2. Under strong light or bad diffuse reflectance of target, please use a reflection board.

3. Operating temperature -10 ℃~50 ℃ can be customized.
