Update to TOF High Frequency 500HZ Laser Ranging Module

JRT Laser Ranging released new high frequency ranging modules during the National Day in October: PTFS-HF and PTFS-H50 series, which are upgraded from PTFS-100 and PTFS-400 and add high frequency TOF laser ranging sensors.

PTFS-100 is a TOF ranging sensor with a measurement frequency of 100HZ and a measurement distance of 100m. Based on market and customer needs, the PTFS-HF series adds 200HZ and 500HZ, and the blind area distance is optimized from 3m to 0.5m, maintaining a measurement distance of 100m and a measurement accuracy of 0.5m-1m, which is suitable for dynamic measurement scenarios with higher frequency requirements.

PTFS-400 is a 400m pulse long distance measurement module with a measurement frequency of only 1HZ, while the PTFS-H50 series has upgraded the measurement frequency to 50HZ, and the measurement distance has been increased to 150m, 200m and 400m, while maintaining the measurement accuracy of 1m, and the measurement temperature can reach -20 degrees to 50 degrees, which can be used for outdoor long distance ranging targets.

In addition, the PTFS-700 series maintains the 700m measurement distance unchanged, and can customize the measurement frequency of 1-10HZ. In addition, the PTF-1200 laser ranging telescope module series, originally measuring distances of 800m, 1000m and 1200m, currently upgrades the software and can customize 3000m measurement distance sensors.

If you have measurement project requirements, you can contact JRT at any time to select and answer technical questions at demi@jrt-measure.com.
